Author Topic: Jeep CJ/YJ 4x4 Rock Crawler Buggy  (Read 3315 times)

Jeep CJ/YJ 4x4 Rock Crawler Buggy
« on: 12/16/13, 02:11PM »

Offline idoroks

  • City Slicker
  • *
  • Posts: 7

1976 CJ-7 body transplanted to a YJ frame. It has a tubed rear section. Full roll cage/slider bars. 115” wheelbase. 304 v-8 with RV cam and Edlebrock performer intake and block hugger headers. Th-400 turbo tranny with an Allison 600 stall torque converter. Art Carr gated shifter. Klune-V 4:1 planetary gear box and an NP 205 transfer case. The 205 has 32 spline front and rear output and twin stick shifters. It has 4 optional crawl rations; 1:1 high range, 2:1 low t-case, 4:1 klune-v and 8:1 low t-case/low klune v.  Off Again double diaphragm brake booster with chevy 2 ½ ton truck master cylinder and adjustable proportioning valve Front driveshaft is .250 wall tubing. Front Dana 60 with 4:10 gears and Spartan Locker, high steer arms and grad 8 studs. It has Superwinch lock outs.  Great Lakes Off-Road 3/8” diff covers front and rear. Front triangulated 4Link suspension with 14” Fox Shock Spring over coils. Currie Anti-Rock sway bar. Full Hydraulic steering with PSC Super pump and remote reservoir, 8”x2” ram on a solid and sleeved tie rod with hiem joints. Boat sided, flat belly panned and oil pan skid plates. Rear 14 bolt axle with Detroit locker, 4:10 gears, shaved and pinion guard. Rear double triangulated suspension with ¼ elliptical springs and regular shocks. Rear will articulate about 44” from full compression to full droop. Rear drive shaft is a Bad Boy Jr. 60 degree CV with 2 “X .250 wall tubing. 39.5 swamper IROKS with 90% tread on Stazworks 16”x10.5” double beadlock wheels. Removable racing steering wheel. Running on full propane system. On board air with 1 gallon tank and York pump. Dual Optima red top batteries. PRP suspension seats sitting on integrated cage, 3 point harnesses. Ramsey Platinum 9,000 lb winch with internal and external switches. Bikini top and 2 sets of soft doors. Built in tool/parts box. 60” hi lift jack and mounting. Uniden CB and antennae. Fire Extinquisher. Comes with 5 aluminum propane bottles, spare set of lockouts, spare drive shafts and a spare brand new 39.5” IROK tire mounted on black steel rim.  This rig will climb about everything you can point it at. It is very stable and has crazy articulation. Asking $11,500.


Re: Jeep CJ/YJ 4x4 Rock Crawler Buggy
« Reply #1 on: 12/17/13, 09:42AM »

Offline Jacksfork

  • Ranch Mayor
  • Ranch Local
  • *
  • Posts: 2535
  • "YOU GONNA PULL THEM PISTOLS OR WHISTLE DIXIE!!"
    • Southern Missouri Off Road Ranch
Awesome rig at a great price!!   8)
